1. Compatible with a multitude of alternator types, the DC-DC battery charger offers correct charging for AGM, Flooded, Gel, and Lithium batteries.
2. The DC-DC battery charger will charge your house batteries from the starter battery by 3-stage charging (Bulk, Boost, and Float), to make sure it optimally and automatically charge to 100%.
3. Offers Over-voltage Protection, Over-temperature Protection, and Reverse Polarity Protection to ensure the operation safety. It also isolates the input and output to prevent voltage transmission errors and interfere with house battery charging.
4. The DC-DC battery charger is capable of identifying whether the generator is started, to prevent over-discharge of the starting battery and protect the generator.
5. The compact and robust design makes it suitable for all conditions.
12V 20A DC-DC Battery Charger (SPDCDC-1220) for RV’s, commercial vehicles, boats, yachts, etc
₹23,999.00 ₹14,899.00
You Save: 38%
1. Compatible Multiple Battery Types.
2. Smart 3-stage Charging
3. Various Protections For Ultra Safety
4.Protect Your Starter Battery
5. Reliable Quality, compact and robust suitable for all conditions.
Out of stock
Additional information
Weight | 1.4 kg |
---|---|
Dimensions | 215 × 175 × 70 cm |
Model No | SPDCDC-1220 |
Charger Type | 12V DC – 12V DC |
Wattage | 240W |
Nominal Input Voltage | 12V DC |
Input Voltage Range | 8 – 16V DC |
Rated Charging Current | 20A |
Charging Voltage Range | 13.2 V – 14.7 V (Depending on DIP Switch) |
Max Rated Output Power | 240W |
Low Current Mode | 10A |
Standby Current | <0.45A |
Residual Ripple of Output Voltage at rated current | <= 50 mV |
Efficiency | <=90% |
Application Battery | Lead Acid battery, lithium battery, GEL, AGM |
Application | RV's, commercial vehicles, boats, yachts and many more application |
Protection | overload, short circuit, etc |
Package Size in mm | 215 X 175 X 70 |
Package Weight in Kgs | 1.4 |
